The FlashCut CNC Pro-Series and Titanium Servo Control Systems, featuring FlashCut CNC Software and integrated USB Signal Generator, drive any machine tool with power, smoothness and precision. The Pro-Series Servos feature State-of-the-art, closed-loop digital PID control providing accurate positioning even under the most strenuous conditions. The Titanium Series Controllers have the same power as the Pro-Series servos with an integrated 19.5″ touch screen PC interface along with optional instrumentation such as E-stop, feed-hold, feedrate override, program start and joystick jogging all in a mountable NEMA industrial enclosure.

Product

25A Pro-Series Servo Controller

Titanium Servo Controller


Part Number (X = # of axis)

6501-X-250-V

7501-X-250-V

Continuous Current [A]

12

12

Peak Current [A]

25

25

Bus Voltage [VDC]

80

80

Input Voltage [VAC]

 115 or 230

115 or 230

Commonly Works With These NEMA size Servo Motors

 17, 23, 34, 42

17, 23, 34, 42, 56

Weight [lbs] ([kg])

16 (7.3)

85 (38.5)

L x W x H  [in] ([mm])

 6 x 9.1 x 2.7 (150 x 231 x 69)

18 x 22 x 25
(456 x 553 x 638)

Diagram

Motors
FlashCut also offers a wide range of servo motors to suit your needs including NEMA frame sizes 17, 23, 34, 42 and 56. All of our motors come with shielded power and signal connectors and optional cables up to 75 ft (23 m) ready to plug directly into our servo controllers. The FlashCut CNC Servo Control System also works with most existing brush-type or brushless servo motors using linear or rotary encoders.
