Platinum Servo CNC Sub Panel

Overview

Platinum Servo CNC Sub Panel

The FlashCut CNC Platinum Servo CNC Sub-Panel along with our Platinum series servo motors provides the ultimate in power and precision.  It features a sinusoidal servo drives, auto tuning, and power of up to 18A and 680VDC giving you high torque and high speed.  Like all of our controls, it features the FlashCut CNC Software and integrated USB Signal Generator and drives any machine tool with power, smoothness and precision. State-of-the-art, closed-loop digital PID control provides accurate positioning even under the most strenuous conditions.

Features

  • Powers the ultimate in speed and torque with a 200-480 3-phase VAC (280-680VDC) voltage bus delivering 6A continuous, 18A peak current per channel
  • Sinusoidal PID control loop for extremely smooth, accurate motion
  • Up to 6 axes of motion
  • In application auto-tune takes the guesswork out of precision tuning
  • Runs a wide range of servo motors
  • Up to 32 optically isolated inputs, 32 digital outputs, 2 analog inputs and 2 analog outputs
  • Made in the USA
